Condenser dryer DH-300 BY

The condenser dryer DH-300 BY is the largest condenser dryer available for rental in the Netherlands…

Featured specs
Air volume 5,000 m³/h
Maximum capacity 600 l / 24 h

Category:

Description

The condenser dryer DH-300 BY is the largest condenser dryer available for rental in the Netherlands. With a dehumidification capacity of 600 liters per day, it is a dryer to be impressed by. Built for rental in a robust frame so that the machine can be easily transported and is protected against damage.
Fitted as standard with a condensation water pump so that the machine can be used flexibly.

For temporary climate solutions for business, industry, construction and ATEX environments, CSrental B.V. is the place to be.
CSrental B.V. has professional consultants who can work with you to find the best rental solution for your business.
Call or email us for a customized quote.

Minimum rental: 7 days

Air volume 5,000 m³/h

Maximum capacity 600 l / 24 h

Temperature range 0°C to 35°C

Connection voltage 400 V / 50 Hz

Input power 7.3 kW

Rated current consumption 16A

Noise level @ 3 m 66 dB (A)

Hygrostat connection Yes

Dimensions L x W x H 980 x 1,180 x 1,176 mm

(height is 2,150 mm with hose connection)

Weight 305 kg

Plug CEE 400V/ 32A – 5 pin

Warning

In a condensation dryer, the moist air is cooled using the evaporator section of a closed refrigeration system. The condensation dryer contains an odourless, flammable refrigerant that can cause fires and explosions if handled incorrectly. The refrigerant circuit is under pressure. Therefore, do not use objects to speed up the defrosting process. Do not store the dehumidifier in areas with permanent ignition sources, for example; open fire, working gas appliances or electric heaters.

The condenser dryer must not be used in:

  • In rooms with a potentially explosive atmosphere;
  • In rooms with an aggressive atmosphere (e.g. caused by chemicals);
  • In rooms containing water with a pH value below 7.0 or above 7.4;
  • In areas with salt or liquids with a salt content > 1%, e.g. salt baths;
  • In rooms with ozone-treated air, high solvent concentrations or high dust emissions.

Related products

  • General accessories

    View the range of general accessories here
    Extra gegevens

    View the range of general accessories here:

    ItemSizesSuitable for suction sideSuitable for press silk
    Connection socket for connecting attachments100 to 800 mmJJ
    Coupling bush for connecting pipes100 to 800 mmJJ
    T-piece100 to 800 mmJJ
    Y piece100 to 800 mmJJ
    Y-piece flexible130 to 600 mmNJ
    Flange edge100 to 800 mmJJ
    Control valve100 to 800 mmJJ
    45° bend100 to 800 mmJJ
    90° bend100 to 800 mmJJ
    Expiry100 to 600 mmJJ
    Very flexiblefrom 300mmNJ
    Filter cartridges100 to 600 mmJJ
    Clamp Band80 to 800 mmn/an/a
  • Condensation drain hose

    Length is based on what is required. minimum rental: 7 days
  • Extension cables

    View the range of extension cables here.
    Extra gegevens
    Extension cablesConnection voltagePlugLengthDiameterATEX zone
    Default230V230V / 16ACEE 7/7 type E/F25m3*2.5mm²n/a
    230V230V / 16A230 V / 16 A – 3 pole15m3*2.5mm²n/a
    400V400V / 16A400 V / 16 A – 5 pin25m5*2.5mm²n/a
    400V400V / 32A400 V / 32 A – 5 pin25m5*6mm²n/a
    400V400V / 63A400 V / 63 A – 5 pin25m5*16mm²n/a
    400V400V / 125A400 V / 125 A – 5 pin25m5*35mm²n/a
    ATEX42V42V / 16AATX 42V / 16A – 3 pin25m3*2.5mm²zone 1 and 21
    230V230V / 16ACEAG 230 V / 16 A – 3 poles25m3*2.5mm²zone 1 and 21
    400V400V / 16ACEAG 400 V / 16 A – 3 poles25m5*2.5mm²zone 1 and 21
    400V400V / 32ACEAG 400 V / 32 A – 5 pin25m5*6mm²zone 1 and 21
    400V400V / 63ACEAG 400 V / 63 A – 5 pin25m5*16mm²zone 1 and 21
  • Hose connections

    View the range of connecting hoses here.
    Extra gegevens
    Connecting hoseApplicationLinkLength
    Air conditioning3/8 flat face5m
    3/8 flat face10m
    3/8 flat face15m
    Chillers / Boilers1¼” cam lock5m
    1¼” cam lock10m
    2″ cam lock3m
    2″ cam lock5m
    2″ cam lock10m
    Electric water heater1″ geka5m
    Underfloor heating1″geka10m
    Heating diesel heaters3/8 flat face5m
    3/8 flat face10m
    Compressed airludecke10m
    Claw couplingludecke adjustable10m
    Common links:Bauwer, boilersStorz coupling, fire brigadePerrot coupling, agriculture
  • Meter climate control

    View the range of meters for climate control here.
    Extra gegevens

    View the range of meters for controlling machines below.

    Atex thermostaat
    ATEX thermostat
    II 2G IIC T4 – II 2D IIIC T130
    CO² regulationData loggerDew point controlDigital thermostat and hygrostatDifferential pressure gauge
    TypethermostatCO² protectiondelete receiveddehumidificationthermostat and hygrostatventilation
    Control oftemperatureair qualitymonitoringdew point monitoringtemperature and humidityair volume
    Deployment areaHeatingventilationheating, cooling, dehumidification and humidificationdehumidifiersheating, cooling, dehumidification and humidificationoperational reliability ventilation
    Measure value-40 – +40 °C0 – 2,000ppm0 – 100 % RH
    -40 – 70+ °C
    0 – 100% RH0 – 100 % RH
    -20 – 80+ °C
    0 – 500 Pa
    Accuracy2% +/-2% +/-2% +/-2% +/-1.5% +/-2% +/-
    Switching range2.5A / 230V230 VBattery 3.6V2 A / 230 V2 A / 230 V2 A / 230 V
    Hygrostaat adsorptiedroger
    Hygrostat
    Suitable for MDC adsorption dryers
    Plug-in humidistat
    Suitable for 230 V dryers
    Plug thermostat
    Suitable for 230 V heaters
    Thermostat
    Suitable for the DFE 65 and 95
    Thermostat
    Suitable for the DFE 80 T
    Thermostat oil heaters
    Typehumidistatplug hygrostatplug thermostatthermostatthermostatthermostat
    Control ofhumidityhumiditytemperaturetemperaturetemperaturetemperature
    Deployment areadehumidification and humidificationdehumidification and humidificationheatingheatingheatingheating
    Measure value30 – 100% RH10 – 90 % RH0 – 60% RH0 – 40% RH0 – 40% RH0 – 40% RH
    Accuracy3% +/-5% +/-5% +/-3% +/-3% +/-3% +/-
    Switching range5 A / 230 V
    2 A / 230 V
    2 A / 230 V2 A / 230 V25 A / 400 V2 A / 230 V2 A / 230 V
  • Hose connector

    Hose connection piece for the DH 150 and the DH 300.
